camp_camp_box_model_data::camp_box_model_data_t Type Reference

CAMP Box model. More...

Collaboration diagram for camp_camp_box_model_data::camp_box_model_data_t:

Public Member Functions
procedure	run (this, output_file_unit)
	Run the box model.
procedure	create_gnuplot_config_file (this, file_prefix)
	Create a plotting script for the results.
procedure	print (this, file_unit)
	Print the box model configuration.
final	finalize (this)
	Finalize the box model.

Public Attributes
type(camp_state_t), pointer	camp_state
	CAMP state.
type(camp_state_t), pointer	initial_camp_state
	Initial CAMP state.
type(string_t), dimension(:), allocatable	spec_names
	State species names.
integer(kind=i_kind)	num_steps
	Number of time steps.
real(kind=dp)	time_step__s
	Time step length [s].
real(kind=dp)	total_time__s
	Total integration time [s].
type(profile_t)	temperature__k
	Temperature [K] profile.
type(profile_t)	pressure__pa
	Pressure [Pa] profile.
type(rxn_profile_t), dimension(:), allocatable	rxn_profiles
	Reaction profiles.
type(aero_rep_profile_t), dimension(:), allocatable	aero_rep_profiles
	Aerosol representation profiles.

Private Attributes
type(camp_core_t), pointer	camp_core
	CAMP core.

Detailed Description

CAMP Box model.

Constructor for camp_box_model_data_t.

Definition at line 136 of file camp_box_model_data.F90.

Constructor & Destructor Documentation

finalize()

final camp_camp_box_model_data::camp_box_model_data_t::finalize ( type(camp_box_model_data_t), intent(inout) this )

final

Finalize the box model.

Parameters

[in,out]

this

CAMP box model

Definition at line 132 of file camp_box_model_data.F90.

Here is the call graph for this function:

Member Function/Subroutine Documentation

create_gnuplot_config_file()

procedure camp_camp_box_model_data::camp_box_model_data_t::create_gnuplot_config_file	(	class(camp_box_model_data_t), intent(in)	this,
		character(len=*), intent(in)	file_prefix )

Create a plotting script for the results.

Parameters

[in]	this	Box model data
[in]	file_prefix	Prefix for the results file (assumes a results file name of ‘'file_prefix’_results.txt`)

Definition at line 128 of file camp_box_model_data.F90.

print()

procedure camp_camp_box_model_data::camp_box_model_data_t::print	(	class(camp_box_model_data_t), intent(in)	this,
		integer(kind=i_kind), intent(in), optional	file_unit )

Print the box model configuration.

Parameters

[in]	this	Box model data
[in]	file_unit	Output file unit

Definition at line 130 of file camp_box_model_data.F90.

run()

procedure camp_camp_box_model_data::camp_box_model_data_t::run	(	class(camp_box_model_data_t), intent(inout)	this,
		integer(kind=i_kind), intent(in), optional	output_file_unit )

Run the box model.

Parameters

[in,out]	this	CAMP box model
[in]	output_file_unit	Output file unit

Definition at line 126 of file camp_box_model_data.F90.

Member Data Documentation

aero_rep_profiles

type(aero_rep_profile_t), dimension(:), allocatable camp_camp_box_model_data::camp_box_model_data_t::aero_rep_profiles

Aerosol representation profiles.

Definition at line 123 of file camp_box_model_data.F90.

camp_core

type(camp_core_t), pointer camp_camp_box_model_data::camp_box_model_data_t::camp_core

private

CAMP core.

Definition at line 103 of file camp_box_model_data.F90.

camp_state

type(camp_state_t), pointer camp_camp_box_model_data::camp_box_model_data_t::camp_state

CAMP state.

Definition at line 105 of file camp_box_model_data.F90.

initial_camp_state

type(camp_state_t), pointer camp_camp_box_model_data::camp_box_model_data_t::initial_camp_state

Initial CAMP state.

Definition at line 107 of file camp_box_model_data.F90.

num_steps

integer(kind=i_kind) camp_camp_box_model_data::camp_box_model_data_t::num_steps

Number of time steps.

Definition at line 111 of file camp_box_model_data.F90.

pressure__pa

type(profile_t) camp_camp_box_model_data::camp_box_model_data_t::pressure__pa

Pressure [Pa] profile.

Definition at line 119 of file camp_box_model_data.F90.

rxn_profiles

type(rxn_profile_t), dimension(:), allocatable camp_camp_box_model_data::camp_box_model_data_t::rxn_profiles

Reaction profiles.

Definition at line 121 of file camp_box_model_data.F90.

spec_names

type(string_t), dimension(:), allocatable camp_camp_box_model_data::camp_box_model_data_t::spec_names

State species names.

Definition at line 109 of file camp_box_model_data.F90.

temperature__k

type(profile_t) camp_camp_box_model_data::camp_box_model_data_t::temperature__k

Temperature [K] profile.

Definition at line 117 of file camp_box_model_data.F90.

time_step__s

real(kind=dp) camp_camp_box_model_data::camp_box_model_data_t::time_step__s

Time step length [s].

Definition at line 113 of file camp_box_model_data.F90.

total_time__s

real(kind=dp) camp_camp_box_model_data::camp_box_model_data_t::total_time__s

Total integration time [s].

Definition at line 115 of file camp_box_model_data.F90.

---

The documentation for this type was generated from the following file:

• camp_box_model_data.F90
