camp_property::property_link_t Type Reference

Property link data. More...

Collaboration diagram for camp_property::property_link_t:

Public Member Functions
procedure	key (this)
	Get the key name.
procedure	set_value (this, val)
	Set the value.
procedure	value_int (this)
	Get the int value.
procedure	value_real (this)
	Get the real value.
procedure	value_logical (this)
	Get the logical value.
procedure	value_string (this)
	Get the string value.
procedure	value_property_t (this)
	Get the property sub-set.
procedure	print (this, suffix, file_unit)
	Print the contents of a property key-value pair.
final	link_finalize (this)
	Finalize.
	link_finalize_array (this)
	Finalize the property_link_t array.

Public Attributes
class(*), pointer	val => null()
	Value.
type(property_link_t), pointer	next_link => null()
	Next link.

Private Attributes
character(:), allocatable	key_name
	Key name.

Detailed Description

Property link data.

An element of a property data set. Property values can be of any primitive type or be a pointer to a sub-set of property data. The property_link_t object is for internal use in the camp_property module. All interactions with property data should be made using property_t objects.

Definition at line 123 of file property.F90.

Constructor & Destructor Documentation

link_finalize()

final camp_property::property_link_t::link_finalize ( type(property_link_t), intent(inout) this )

final

Finalize.

Parameters

[in,out]

this

Property key-value pair

Definition at line 119 of file property.F90.

Here is the call graph for this function:

Member Function/Subroutine Documentation

key()

procedure camp_property::property_link_t::key

(

class(property_link_t), intent(in)

this

)

Get the key name.

Returns

Key name

Parameters

[in]

this

Property key-value pair

Definition at line 103 of file property.F90.

link_finalize_array()

camp_property::property_link_t::link_finalize_array

(

type(property_link_t), dimension(:), intent(inout)

this

)

Finalize the property_link_t array.

Parameters

[in,out]

this

Property key-value pair array

Definition at line 119 of file property.F90.

print()

procedure camp_property::property_link_t::print	(	class(property_link_t), intent(in)	this,
		character(len=*), intent(in)	suffix,
		integer(kind=i_kind), intent(in), optional	file_unit )

Print the contents of a property key-value pair.

Parameters

[in]	this	Property key-value pair
[in]	suffix	Text to append to the end of the line
[in]	file_unit	File unit for output

Definition at line 117 of file property.F90.

set_value()

procedure camp_property::property_link_t::set_value	(	class(property_link_t), intent(inout)	this,
		class(*), intent(in)	val )

Set the value.

Parameters

[in,out]	this	Property key-value pair
[in]	val	New value

Definition at line 105 of file property.F90.

value_int()

procedure camp_property::property_link_t::value_int

(

class(property_link_t), intent(in)

this

)

Get the int value.

Returns

Value

Parameters

[in]

this

Property key-value pair

Definition at line 107 of file property.F90.

value_logical()

procedure camp_property::property_link_t::value_logical

(

class(property_link_t), intent(in)

this

)

Get the logical value.

Returns

Value

Parameters

[in]

this

Property key-value pair

Definition at line 111 of file property.F90.

value_property_t()

procedure camp_property::property_link_t::value_property_t

(

class(property_link_t), intent(in)

this

)

Get the property sub-set.

Returns

Value

Parameters

[in]

this

Property key-value pair

Definition at line 115 of file property.F90.

value_real()

procedure camp_property::property_link_t::value_real

(

class(property_link_t), intent(in)

this

)

Get the real value.

Returns

Value

Parameters

[in]

this

Property key-value pair

Definition at line 109 of file property.F90.

value_string()

procedure camp_property::property_link_t::value_string

(

class(property_link_t), intent(in)

this

)

Get the string value.

Returns

Value

Parameters

[in]

this

Property key-value pair

Definition at line 113 of file property.F90.

Member Data Documentation

key_name

character(:), allocatable camp_property::property_link_t::key_name

private

Key name.

Definition at line 96 of file property.F90.

next_link

type(property_link_t), pointer camp_property::property_link_t::next_link => null()

Next link.

Definition at line 100 of file property.F90.

val

class(*), pointer camp_property::property_link_t::val => null()

Value.

Definition at line 98 of file property.F90.

---

The documentation for this type was generated from the following file:

• property.F90
