Aerosol representation functions. More...

Include dependency graph for aero_rep_solver.c:

Macros
#define	AERO_REP_SINGLE_PARTICLE 1

#define	AERO_REP_MODAL_BINNED_MASS 2

Functions
int	aero_rep_get_used_jac_elem (ModelData model_data, int aero_rep_idx, int aero_phase_idx, bool jac_struct)
	Flag Jacobian elements used to calculated mass, volume, etc. More...

void	aero_rep_get_dependencies (ModelData model_data, bool state_flags)
	Get state array elements used by aerosol representation functions. More...

void	aero_rep_update_env_state (ModelData *model_data)
	Update the aerosol representations for new environmental conditions. More...

void	aero_rep_update_state (ModelData *model_data)
	Update the aerosol representations for a new state. More...

void	aero_rep_get_effective_layer_radius__m (ModelData model_data, int aero_rep_idx, int aero_phase_idx, double layer_radius, double *partial_deriv)
	Get the effective radius of a specified layer, \(r_{layer}\) (m) More...

void	aero_rep_get_effective_radius__m (ModelData model_data, int aero_rep_idx, int aero_phase_idx, double radius, double *partial_deriv)
	Get the effective particle radius, \(r_{eff}\) (m) More...

void	aero_rep_get_interface_surface_area__m2 (ModelData model_data, int aero_rep_idx, int aero_phase_idx_first, int aero_phase_idx_second, double surface_area, double *partial_deriv)
	Get the surface area of interfacial layer between two phases (m^2) More...

void	aero_rep_get_layer_thickness__m (ModelData model_data, int aero_rep_idx, int aero_phase_idx, double layer_thickness, double *partial_deriv)
	Get the thickness of a particle layer (m) More...

void	aero_rep_get_number_conc__n_m3 (ModelData model_data, int aero_rep_idx, int aero_phase_idx, double number_conc, double *partial_deriv)
	Get the particle number concentration \(n\) ( \(\mbox{\si{\#\per\cubic\metre}}\)) More...

int	aero_rep_get_aero_conc_type (ModelData *model_data, int aero_rep_idx, int aero_phase_idx)
	Check whether aerosol concentrations are per-particle or total for each phase. More...

void	aero_rep_get_aero_phase_mass__kg_m3 (ModelData model_data, int aero_rep_idx, int aero_phase_idx, double aero_phase_mass, double *partial_deriv)
	Get the total mass of an aerosol phase in this representation \(m\) ( \(\mbox{\si{\kilogram\per\cubic\metre}}\)) More...

void	aero_rep_get_aero_phase_avg_MW__kg_mol (ModelData model_data, int aero_rep_idx, int aero_phase_idx, double aero_phase_avg_MW, double *partial_deriv)
	Get the average molecular weight of an aerosol phase in this representation \(m\) ( \(\mbox{\si{\micro\gram\per\cubic\metre}}\)) More...

void	aero_rep_add_condensed_data (int aero_rep_type, int n_int_param, int n_float_param, int n_env_param, int int_param, double float_param, void *solver_data)
	Add condensed data to the condensed data block for aerosol representations. More...

void	aero_rep_update_data (int cell_id, int aero_rep_id, int update_aero_rep_type, void update_data, void *solver_data)
	Update aerosol representation data. More...

void	aero_rep_print_data (void *solver_data)
	Print the aerosol representation data. More...

void	aero_rep_free_update_data (void *update_data)
	Free an update data object. More...

Detailed Description

Aerosol representation functions.

Definition in file aero_rep_solver.c.

Macro Definition Documentation

◆ AERO_REP_MODAL_BINNED_MASS

#define AERO_REP_MODAL_BINNED_MASS 2

Definition at line 20 of file aero_rep_solver.c.

◆ AERO_REP_SINGLE_PARTICLE

#define AERO_REP_SINGLE_PARTICLE 1

Definition at line 19 of file aero_rep_solver.c.

Function Documentation

◆ aero_rep_add_condensed_data()

void aero_rep_add_condensed_data	(	int	aero_rep_type,
		int	n_int_param,
		int	n_float_param,
		int	n_env_param,
		int *	int_param,
		double *	float_param,
		void *	solver_data
	)

Add condensed data to the condensed data block for aerosol representations.

Parameters

aero_rep_type	Aerosol representation type
n_int_param	Number of integer parameters
n_float_param	Number of floating-point parameters
n_env_param	Number of environment-dependent parameters
int_param	Pointer to integer parameter array
float_param	Pointer to floating-point parameter array
solver_data	Pointer to solver data

Definition at line 582 of file aero_rep_solver.c.

◆ aero_rep_free_update_data()

void aero_rep_free_update_data ( void * update_data )

Free an update data object.

Parameters

update_data Object to free

Definition at line 728 of file aero_rep_solver.c.

◆ aero_rep_get_aero_conc_type()

int aero_rep_get_aero_conc_type	(	ModelData *	model_data,
		int	aero_rep_idx,
		int	aero_phase_idx
	)

Check whether aerosol concentrations are per-particle or total for each phase.

Parameters

model_data	Pointer to the model data
aero_rep_idx	Index of aerosol representation to use for calculation
aero_phase_idx	Index of the aerosol phase within the aerosol representation

Returns: 0 for per-particle; 1 for total for each phase

Definition at line 431 of file aero_rep_solver.c.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ aero_rep_get_aero_phase_avg_MW__kg_mol()

void aero_rep_get_aero_phase_avg_MW__kg_mol	(	ModelData *	model_data,
		int	aero_rep_idx,
		int	aero_phase_idx,
		double *	aero_phase_avg_MW,
		double *	partial_deriv
	)

Get the average molecular weight of an aerosol phase in this representation \(m\) ( \(\mbox{\si{\micro\gram\per\cubic\metre}}\))

Calculates total aerosol phase mass, \(m\) ( \(\mbox{\si{\micro\gram\per\cubic\metre}}\)), as well as the set of \(\frac{\partial m}{\partial y}\) where \(y\) are variables on the solver state array.

Parameters

model_data	Pointer to the model data
aero_rep_idx	Index of aerosol representation to use for calculation
aero_phase_idx	Index of the aerosol phase within the aerosol representation
aero_phase_avg_MW	Pointer to hold calculated average MW in the aerosol phase ( \(\mbox{\si{\kilogram\per\mole}}\))
partial_deriv	Pointer to the set of partial derivatives to be calculated \(\frac{\partial m}{\partial y}\), or a NULL pointer if no partial derivatives are needed

Definition at line 537 of file aero_rep_solver.c.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ aero_rep_get_aero_phase_mass__kg_m3()

void aero_rep_get_aero_phase_mass__kg_m3	(	ModelData *	model_data,
		int	aero_rep_idx,
		int	aero_phase_idx,
		double *	aero_phase_mass,
		double *	partial_deriv
	)

Get the total mass of an aerosol phase in this representation \(m\) ( \(\mbox{\si{\kilogram\per\cubic\metre}}\))

Calculates total aerosol phase mass, \(m\) ( \(\mbox{\si{\kilogram\per\cubic\metre}}\)), as well as the set of \(\frac{\partial m}{\partial y}\) where \(y\) are variables on the solver state array.

Parameters

model_data	Pointer to the model data
aero_rep_idx	Index of aerosol representation to use for calculation
aero_phase_idx	Index of the aerosol phase within the aerosol representation
aero_phase_mass	Pointer to hold calculated aerosol-phase mass, \(m\) ( \(\mbox{\si{\kilogram\per\cubic\metre}}\))
partial_deriv	Pointer to the set of partial derivatives to be calculated \(\frac{\partial m}{\partial y}\), or a NULL pointer if no partial derivatives are needed

Definition at line 485 of file aero_rep_solver.c.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ aero_rep_get_dependencies()

void aero_rep_get_dependencies	(	ModelData *	model_data,
		bool *	state_flags
	)

Get state array elements used by aerosol representation functions.

Parameters

model_data	A pointer to the model data
state_flags	An array of flags the length of the state array indicating species used

Definition at line 69 of file aero_rep_solver.c.

Here is the call graph for this function:

◆ aero_rep_get_effective_layer_radius__m()

void aero_rep_get_effective_layer_radius__m	(	ModelData *	model_data,
		int	aero_rep_idx,
		int	aero_phase_idx,
		double *	layer_radius,
		double *	partial_deriv
	)

Get the effective radius of a specified layer, \(r_{layer}\) (m)

Calculates the effective radius of a specified layer \(r_{layer}\) (m), as well as the set of \(\frac{\partial r_{layer}}{\partial y}\) where \(y\) are variables on the solver state array.

Parameters

model_data	Pointer to the model data
aero_rep_idx	Index of aerosol representation to use for calculation
aero_phase_idx	Index of the aerosol phase within the aerosol representation
layer_radius	Pointer to hold effective layer radius (m)
partial_deriv	Pointer to the set of partial derivatives to be calculated \(\frac{\partial r_{eff}}{\partial y}\), or a NULL pointer if no partial derivatives are needed

Definition at line 198 of file aero_rep_solver.c.

Here is the call graph for this function:

◆ aero_rep_get_effective_radius__m()

void aero_rep_get_effective_radius__m	(	ModelData *	model_data,
		int	aero_rep_idx,
		int	aero_phase_idx,
		double *	radius,
		double *	partial_deriv
	)

Get the effective particle radius, \(r_{eff}\) (m)

Calculates effective particle radius \(r_{eff}\) (m), as well as the set of \(\frac{\partial r_{eff}}{\partial y}\) where \(y\) are variables on the solver state array.

Parameters

model_data	Pointer to the model data
aero_rep_idx	Index of aerosol representation to use for calculation
aero_phase_idx	Index of the aerosol phase within the aerosol representation
radius	Pointer to hold effective particle radius (m)
partial_deriv	Pointer to the set of partial derivatives to be calculated \(\frac{\partial r_{eff}}{\partial y}\), or a NULL pointer if no partial derivatives are needed

Definition at line 246 of file aero_rep_solver.c.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ aero_rep_get_interface_surface_area__m2()

void aero_rep_get_interface_surface_area__m2	(	ModelData *	model_data,
		int	aero_rep_idx,
		int	aero_phase_idx_first,
		int	aero_phase_idx_second,
		double *	surface_area,
		double *	partial_deriv
	)

Get the surface area of interfacial layer between two phases (m^2)

Calculates surface area of a interfacial layer (m^2), as well as the set of \(\frac{\partial A}{\partial y}\) where \(y\) are variables on the solver state array.

Parameters

model_data	Pointer to the model data
aero_rep_idx	Index of aerosol representation to use for calculation
aero_phase_idx_first	Index of the first aerosol phase within the aerosol representation
aero_phase_idx_second	Index of the second aerosol phase within the aerosol representation
surface_area	Pointer to surface area of interfacial layer (m^2)
partial_deriv	Pointer to the set of partial derivatives to be calculated \(\frac{\partial A}{\partial y}\), or a NULL pointer if no partial derivatives are needed

Definition at line 296 of file aero_rep_solver.c.

Here is the call graph for this function:

◆ aero_rep_get_layer_thickness__m()

void aero_rep_get_layer_thickness__m	(	ModelData *	model_data,
		int	aero_rep_idx,
		int	aero_phase_idx,
		double *	layer_thickness,
		double *	partial_deriv
	)

Get the thickness of a particle layer (m)

Parameters

model_data	Pointer to the model data, including the state array
aero_rep_idx	Index of aerosol representation to use for calculation
aero_phase_idx	Index of the aerosol phase within the representation
layer_thickness	Effective layer thickness (m)
partial_deriv	\(\frac{\partial r_{eff}}{\partial y}\) where \(y\) are species on the state array

Definition at line 338 of file aero_rep_solver.c.

Here is the call graph for this function:

◆ aero_rep_get_number_conc__n_m3()

void aero_rep_get_number_conc__n_m3	(	ModelData *	model_data,
		int	aero_rep_idx,
		int	aero_phase_idx,
		double *	number_conc,
		double *	partial_deriv
	)

Get the particle number concentration \(n\) ( \(\mbox{\si{\#\per\cubic\metre}}\))

Calculates particle number concentration, \(n\) ( \(\mbox{\si{\#\per\cubic\metre}}\)), as well as the set of \(\frac{\partial n}{\partial y}\) where \(y\) are variables on the solver state array.

Parameters

model_data	Pointer to the model data
aero_rep_idx	Index of aerosol representation to use for calculation
aero_phase_idx	Index of the aerosol phase within the aerosol representation
number_conc	Pointer to hold calculated number concentration, \(n\) ( \(\mbox{\si{\#\per\cubic\metre}}\))
partial_deriv	Pointer to the set of partial derivatives to be calculated \(\frac{\partial n}{\partial y}\), or a NULL pointer if no partial derivatives are required

Definition at line 389 of file aero_rep_solver.c.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ aero_rep_get_used_jac_elem()

int aero_rep_get_used_jac_elem	(	ModelData *	model_data,
		int	aero_rep_idx,
		int	aero_phase_idx,
		bool *	jac_struct
	)

Flag Jacobian elements used to calculated mass, volume, etc.

Parameters

model_data	A pointer to the model data
aero_rep_idx	Index of aerosol representation to use for calculation
aero_phase_idx	Index of the aerosol phase within the aerosol representation
jac_struct	1D array of flags indicating potentially non-zero Jacobian elements. (The dependent variable should have been chosen by the calling function.)

Returns: Number of Jacobian elements flagged

Definition at line 33 of file aero_rep_solver.c.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ aero_rep_print_data()

void aero_rep_print_data ( void * solver_data )

Print the aerosol representation data.

Parameters

solver_data Pointer to the solver data

Definition at line 685 of file aero_rep_solver.c.

Here is the call graph for this function:

◆ aero_rep_update_data()

void aero_rep_update_data	(	int	cell_id,
		int *	aero_rep_id,
		int	update_aero_rep_type,
		void *	update_data,
		void *	solver_data
	)

Update aerosol representation data.

Parameters

cell_id	Id of the grid cell to update
aero_rep_id	Aerosol representation id (or 0 if unknown)
update_aero_rep_type	Aerosol representation type to update
update_data	Pointer to data needed for update
solver_data	Pointer to solver data

Definition at line 631 of file aero_rep_solver.c.

Here is the call graph for this function:

◆ aero_rep_update_env_state()

void aero_rep_update_env_state ( ModelData * model_data )

Update the aerosol representations for new environmental conditions.

Parameters

model_data Pointer to the model data

Definition at line 105 of file aero_rep_solver.c.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ aero_rep_update_state()

void aero_rep_update_state ( ModelData * model_data )

Update the aerosol representations for a new state.

Parameters

model_data Pointer to the model data

Definition at line 146 of file aero_rep_solver.c.

Here is the call graph for this function:

Here is the caller graph for this function:

Macros

Functions

Detailed Description

Macro Definition Documentation

◆ AERO_REP_MODAL_BINNED_MASS

◆ AERO_REP_SINGLE_PARTICLE

Function Documentation

◆ aero_rep_add_condensed_data()

◆ aero_rep_free_update_data()

◆ aero_rep_get_aero_conc_type()

◆ aero_rep_get_aero_phase_avg_MW__kg_mol()

◆ aero_rep_get_aero_phase_mass__kg_m3()

◆ aero_rep_get_dependencies()

◆ aero_rep_get_effective_layer_radius__m()

◆ aero_rep_get_effective_radius__m()

◆ aero_rep_get_interface_surface_area__m2()

◆ aero_rep_get_layer_thickness__m()

◆ aero_rep_get_number_conc__n_m3()

◆ aero_rep_get_used_jac_elem()

◆ aero_rep_print_data()

◆ aero_rep_update_data()

◆ aero_rep_update_env_state()

◆ aero_rep_update_state()
